MR111096 GEAR,SPEEDOMETER DRIVEN
Images
4 Images
Compatibility
Mitsubishi MR111096
| Frame | Market | Model | Model Year From | Model Year To | Modification | Diagram |
|---|---|---|---|---|---|---|
| K90# | Japan | K97WG | 05.1996 | 08.2001 | 2800DIESEL/WIDE/4WD | View |
| Frame | Market | Model | Model Year From | Model Year To | Modification | Diagram |
|---|---|---|---|---|---|---|
| V43,45W | North America (PUERTO RICO & GUAM) | V45W | 04.1991 | 12.1999 | 3500/LONG WAGON | View |
| Frame | Market | Model | Model Year From | Model Year To | Modification | Plant | Diagram |
|---|---|---|---|---|---|---|---|
| K80,90# | North America | K96W | 09.1996 | 07.2004 | 3000/4WD - LS/XLS(WIDE),4FA/T CAL | MMNA | View |
| Frame | Market | Model | Model Year From | Model Year To | Modification | Diagram |
|---|---|---|---|---|---|---|
| K80,90# | General (EXPORT) | K96W | 06.1997 | 03.2011 | 3000/4WD | View |
| Frame | Market | Model | Model Year From | Model Year To | Modification | Diagram |
|---|---|---|---|---|---|---|
| V20-50# | Japan | V25W | 10.1990 | 11.1999 | 3500/WIDE/SHORT WAGON - LIMITED EDITION(WIDE/SS4),4FA/T | View |
| Frame | Market | Model | Model Year From | Model Year To | Modification | Diagram |
|---|---|---|---|---|---|---|
| K96W | General (CHINA) | K96W | 10.2002 | 04.2003 | 3000/4WD - GLS(WIDE),4FA/T CHINA/BJC | View |
| Frame | Market | Model | Model Year From | Model Year To | Modification | Diagram |
|---|---|---|---|---|---|---|
| V10-40# | Europe (EUROPE) | V23W | 12.1990 | 04.2004 | 3000/SHORT WAGON - GLS(METAL/WIDE/S-SELECT/S4),4FA/T RHD | View |
| Frame | Market | Model | Model Year From | Model Year To | Modification | Diagram |
|---|---|---|---|---|---|---|
| K90# | Europe (EUROPE) | K96W | 08.1998 | 02.2009 | 3000/4WD - GLS(WIDE/EURO2),4FA/T RHD | View |
| Frame | Market | Model | Model Year From | Model Year To | Modification | Diagram |
|---|---|---|---|---|---|---|
| V30,40# | General (EXPORT) | V45W | 12.1990 | 06.2003 | 3500/LONG WAGON - SEMI-HI-RF/WIDE/SS4,4FA/T TAIWAN | View |
| Frame | Market | Model | Model Year From | Model Year To | Modification | Diagram |
|---|---|---|---|---|---|---|
| V10,20# | General (EXPORT) | V26W | 12.1990 | 06.2003 | 2800D-TURBO/SHORT WAGON - GLS(WIDE/SUPER SELECT),5FM/T S.AFRICA | View |
Information
Speedometer Drive Gear for Accurate Road Speed ?
This transmission speed gear is a small but important part used to send vehicle speed movement from the gearbox to the speedometer system. A good gear helps the driver see correct road speed and mileage, which is important for safe driving, fuel control, service intervals, and legal odometer reading.
Why This Part Is Needed
The part is fitted inside the transmission area and works with the speed sensor or speedometer cable drive. When the output shaft turns, the gear rotates at a matched ratio and transfers this movement into a speed signal. Without this gear working properly, the dashboard speed reading can become wrong or stop completely.
How It Works ⚙️
Its teeth mesh with the internal transmission drive gear. As the vehicle moves, the gear spins smoothly and drives the speed measuring mechanism. Correct tooth shape and material strength are important to prevent slipping, noise, or early wear inside the gearbox housing.
Signs of a Broken Gear
Common Problems
- Speedometer needle not moving
- Incorrect speed display
- Odometer not counting distance
- Check engine light related to speed signal
- Poor automatic transmission shifting on some vehicles
If the gear is worn, cracked, or missing teeth, the vehicle may still drive, but speed information will be unreliable. Replacing it with the correct fitting part restores proper speedometer operation and protects driving accuracy.
Compatible Models
- Pajero Sport
- Challenger
- Montero Sport
- Pajero/Montero Sport
- Pajero
- Montero
- Pajero/Montero<Long>
- Nativa
- Pajero/Montero
- Pajero/Montero<Short>
