  • MH034067 Mitsubishi O/SEAL,M/T MAIN DRIVE PIN

MH034067 Mitsubishi O/SEAL,M/T MAIN DRIVE PIN, Price: 7.38$, Weight: 0.01kg

    • Make Number Name Availability Weight, kg Ship in, Days Price

    Mitsubishi

    MH034067

    O/SEAL,M/T MAIN DRIVE PIN

    		 2

    0.01

    2-3

    7.38$


    Originals

    Make Number Name Availability Weight, kg Processing, days Price
    FUSO
    MH034067
    O/SEAL,M/T MAIN DRIV
    		1
    0.014
    15-20
    5.77$

    Musashi
    MH034067
    TRANSMISSION FR
    		0
    0.014
    4-5
    1.89$
    		 Not Available
    Hyundai / KIA
    MH034067
    SEAL-OIL
    		0
    0.014
    -
    12.91$
    		 Not Available

    Substitutions

    Make Number Name Availability Weight, kg Processing, days Price
    Musashi
    F4129
    OIL SEAL
    		59
    0.015
    4-5
    2.00$


    Compatibility

    FrameMarketModelModel Year FromModel Year ToModificationDiagram
    K90#JapanK94WG05.199608.20012500DIESEL/WIDE/4WD - Z,5FM/T View
    FrameMarketModelModel Year FromModel Year ToModificationPlantDiagram
    K60,70#General (EXPORT)K76T01.199612.20073000/4WD(TRUCK)MMTH View
    FrameMarketModelModel Year FromModel Year ToModificationPlantDiagram
    L04,14#North AmericaL141G01.198304.19913000/RR COIL - HIGH LINE,TRUCK,5FM/T CALMMNA View
    FrameMarketModelModel Year FromModel Year ToModificationPlantDiagram
    K80,90#North AmericaK96W09.199607.20043000/4WD - LS,5FM/T CALMMNA View
    FrameMarketModelModel Year FromModel Year ToModificationDiagram
    K80,90#General (EXPORT)K94W06.199703.20112500DIESEL/4WD View
    FrameMarketModelModel Year FromModel Year ToModificationDiagram
    V20-50#JapanV43W10.199011.19993000/LONG WAGON - VR(WIDE/SS4),5FM/T View
    FrameMarketModelModel Year FromModel Year ToModificationDiagram
    K96WGeneral (CHINA)K96W10.200204.20033000/4WD - GLS(WIDE),5FM/T CHINA View
    FrameMarketModelModel Year FromModel Year ToModificationDiagram
    L04,14#Europe (EUROPE)L149G01.198306.19912500DIESEL/LONG/RR COIL - HIGH-ROOF(I/CLR TURBO),5FM/T RHD View
    FrameMarketModelModel Year FromModel Year ToModificationDiagram
    K90#Europe (EUROPE)K94W08.199802.20092500DIESEL/4WD View
    FrameMarketModelModel Year FromModel Year ToModificationDiagram
    V70#General (EXPORT)V73W02.200012.20063000/LONG WAGON<01M-> - GL(ES4),5FM/T RHD View
    FrameMarketModelModel Year FromModel Year ToModificationDiagram
    V60#General (EXPORT)V63W02.200012.20063000/SHORT WAGON<01M-> - GL(ES4),5FM/T GCC View
    FrameMarketModelModel Year FromModel Year ToModificationPlantDiagram
    K5-7#GeneralK74T06.199507.20052500DIESEL/4WD(TRUCK)MMTH View
    FrameMarketModelModel Year FromModel Year ToModificationPlantDiagram
    K50WGeneralK54W09.200105.20052500DIESEL(PPV)MMTH View
    FrameMarketModelModel Year FromModel Year ToModificationPlantDiagram
    K0-K3#North AmericaK26T05.198605.19963000/4WD(TRUCK)MMNA View

    Manual Transmission Main Drive Pin Oil Seal ?️

    This precision oil seal is fitted in the manual gearbox area where the main drive pin/shaft passes through the case. Its job is simple but critical: keep gear oil inside the transmission while allowing the rotating shaft to spin smoothly. A healthy seal protects bearings, synchros, and gears from running dry and stops oil from reaching the clutch area.

    Why this seal is needed

    Manual transmissions rely on correct oil level and clean lubrication. This seal forms a tight barrier against leaks, heat, and splash lubrication pressure. It also blocks dust and water that can enter around the shaft opening.

    How it works

    A flexible sealing lip rides on the shaft surface, supported by a tension spring. As the shaft rotates, the lip maintains contact and “wipes” oil back inward, preventing seepage even under vibration and load.

    What happens if it’s broken ⚠️

    When worn or hardened, you may see gearbox oil dripping, burning smell, slipping/contaminated clutch, noisy bearings, hard shifting, and accelerated gear wear. Ignoring a leak can lead to low oil level and expensive transmission damage.

    Compatible Models ✅

    • L200
    • Strada G-Wagon
    • Strada
    • Pajero Sport
    • Challenger
    • Montero Sport
    • Pajero/Montero
    • Pajero
    • Montero
    • Truck
    • Pajero/Montero Sport
    • Pajero/Montero<Short>
    • Nativa
    • Pajero/Montero<Long>
