  • 9090105010 Toyota BOLT(FOR FRONT SUSPENSION LOWER ARM NO.2),RH/LH
MakeToyota

9090105010 BOLT(FOR FRONT SUSPENSION LOWER ARM NO.2),RH/LH

Images

9090105010 BOLT(FOR FRONT SUSPENSION LOWER AR

Substitutions

MakeNumberNameAvailabilityProcessing, daysPrice
Toyota
90466T0028
CLAMP OR CLIP, HOSE(FOR RADIATOR INLET)
5
 Dispatch 24h
3.72$

Toyota
90466T0028
CLAMP OR CLIP, HOSE(FOR RADIATOR INLET)
5
2-3
3.10$


Compatibility

Toyota 9090105010

DescriptionModelOptionsProd PeriodDiagram
GXE1#,JCE1#,SXE10SXE10-AEAVFATM,MTM: AUTOMATIC TRANSMISSION; Body: SEDAN; Engine: (3SGE) 2000CC 16-VALVE DOHC EFI10.1998 - 07.2005 View
DescriptionModelOptionsProd PeriodDiagram
JCG1#JCG10-CEAVHBody: SEDAN; Engine: (1JZFSE) 2500CC 24-VALVE DOHC EFI05.2001 - 06.2007 View
DescriptionModelOptionsProd PeriodDiagram
GX90,JZX9#,LX90,SX90SX90-BTPNKATM,MTM: AUTOMATIC TRANSMISSION; Grade: XL TYPE; Engine: (4SFE) 1800CC 16-VALVE DOHC EFI10.1992 - 09.1996 View
DescriptionModelOptionsProd PeriodDiagram
GX90,JZX9#,LX90,SX90LX90-CEPETATM,MTM: AUTOMATIC TRANSMISSION; Grade: SUF TYPE; Engine: (2LTE) 2400CC DIESEL TURBO10.1992 - 09.1996 View
DescriptionModelOptionsProd PeriodDiagram
JZS175JZS175R-AEPQFATM,MTM: AUTOMATIC TRANSMISSION; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Body: SEDAN; Grade: ROYAL SALOON; Fuel Induction: TWIN CAM; Gear Shift Type: ATM, 4-SPEED FLOOR SHIFT; Engine: (2JZGE) 3000CC 24-VALVE DOHC EFI; Destination: GENERAL COUNTRIES09.1999 - 12.2003 View
DescriptionModelOptionsProd PeriodDiagram
GS171,JKS175,JZS17#,UZS17#JZS171-AEPSHATM,MTM: AUTOMATIC TRANSMISSION; Body: SEDAN; Grade: ROYAL EXTRA,ROYAL EXTRA FOUR; Fuel Induction: DIRECT-INJECTION GASOLINE ENGINE; Gear Shift Type: ATM, 4-SPEED FLOOR SHIFT; Engine: (1JZFSE) 2500CC 24-VALVE DOHC EFI08.2001 - 12.2003 View
DescriptionModelOptionsProd PeriodDiagram
GX90,LX90,SX90,JZX9#SX90-ATMEKATM,MTM: MANUAL TRANSMISSION; Grade: GROIRE TYPE; Engine: (4SFE) 1800CC 16-VALVE DOHC EFI10.1992 - 09.1996 View
DescriptionModelOptionsProd PeriodDiagram
GX11#,JZX11#JZX110W-AWASHATM,MTM: AUTOMATIC TRANSMISSION; Body: WAGON; Grade: IR-S TYPE,IR-S FOUR TYPE; Gear Shift Type: ATM, 5-SPEED FLOOR SHIFT; Engine: (1JZFSE) 2500CC 24-VALVE DOHC EFI01.2002 - 06.2007 View
DescriptionModelOptionsProd PeriodDiagram
JCG17JCG17-BEPXFBody: SEDAN; Engine: (2JZGE) 3000CC 24-VALVE DOHC EFI08.2000 - 04.2001 View
DescriptionModelOptionsProd PeriodDiagram
JCG1#JCG10-AEPVFBody: SEDAN; Fuel Induction: TWIN CAM; Gear Shift Type: ATM, 4-SPEED FLOOR SHIFT; Engine: (1JZGE) 2500CC 24-VALVE DOHC EFI05.1998 - 04.2001 View
DescriptionModelOptionsProd PeriodDiagram
GX11#,JZX110JZX110-BEASHATM,MTM: AUTOMATIC TRANSMISSION; Grade: 2.5 TYPE; Gear Shift Type: ATM, 5-SPEED FLOOR SHIFT; Engine: (1JZFSE) 2500CC 24-VALVE DOHC EFI06.2001 - 04.2004 View

Information

Front Lower Control Arm Mounting Bolt (Right/Left) ?

This fastener is a critical piece of your front suspension. It clamps the lower arm to its mounting point, keeping wheel alignment stable and allowing the arm bushings to flex the way they were designed. Without the correct bolt strength and shank fit, the suspension can’t hold geometry under braking, cornering, or bumps.

Why this bolt is needed ✅

The lower arm carries major loads from the wheel into the chassis. This bolt provides the correct clamping force so the arm doesn’t shift, squeak, or “walk” in the bracket. Proper torque keeps the bushing sleeve locked while the rubber isolates vibration.

How it works ⚙️

When tightened to spec, the bolt stretches slightly and acts like a spring, maintaining constant clamp load. The smooth section supports shear forces, while the threads stay out of the main load area for durability.

What happens if it’s worn or broken ?

You may get clunks, wandering steering, uneven tire wear, and poor braking stability. In severe cases the arm can move in the mount, causing sudden misalignment and unsafe handling.

Compatibility

  • Altezza/Altezza Gita
  • Brevis
  • Chaser
  • Cresta
  • Crown
  • Crown/Crown Majesta
  • Mark 2
  • Mark 2/Mark 2 Blit
  • Origin
  • Progres
  • Verossa
