9036947001 Toyota BEARING (FOR REAR AXLE SHAFT), Price: 72.91$, Weight: 1.535kg
| Make | Number | Name | Availability | Weight, kg | Ship in, Days | Price |
|---|---|---|---|---|---|---|
Toyota |
9036947001 |
BEARING (FOR REAR AXLE SHAFT) |
28 |
1.535 |
2-3 |
72.91$ |
Substitutions
| Make | Number | Name | Availability | Weight, kg | Processing, days | Price | |
|---|---|---|---|---|---|---|---|
| KOYO |
HCDU47882LFTRQ
|
DU4788-2LFT, 90369-47001 1 ST GENERATION HUB BEARING (TRB) JAPAN KOYO
|
500 |
1.765
|
4-5
|
33.55$
|
|
| FEBEST |
REAR WHEEL BEARING (47X88X57.5)
|
10 |
1.714
|
2-3
|
32.31$
|
||
| KOYO |
HCDU47882LFT
|
BEARING RR AXLE
|
0 |
1.769
|
4-5
|
38.12$
|
Not Available |
| KOYO |
BEARING RR AXLE
|
0 |
1.765
|
4-5
|
34.26$
|
Not Available |
Compatibility
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| KCH1#,RCH11,VCH1#,2# | RCH11W-GRSGK | ATM,MTM: AUTOMATIC TRANSMISSION; Seating Capacity: 8-SEATER; NO. Of Doors: 4-DOOR; Body: WAGON; Grade: G TYPE; Fuel Induction: ELECTRIC FUEL INJECTION SYSTEM; Engine: (3RZFE) 2700CC EFI | 08.1995 - 04.1998 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| KLH1#,2#,LXH1#,2#,RCH1#,2# | RCH23L-RBMRKW | ATM,MTM: MANUAL TRANSMISSION; Seating Capacity: 3-SEATER; Driver's Position: LEFT-HAND DRIVE VEHICLES; Body: 4 DOOR VAN; Grade: STANDARD TYPE; Fuel Induction: ELECTRIC FUEL INJECTION SYSTEM; Engine: (3RZFE) 2700CC EFI; Destination: EUROPE | 04.1998 - 05.2006 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| KCH4#,LXH4#,RCH4# | RCH42V-SRSDE | ATM,MTM: AUTOMATIC TRANSMISSION; NO. Of Doors: 5-DOOR; Body: VAN; Grade: STANDARD TYPE('99.7- V TYPE); Engine: (1RZE) 2000CC EFI | 07.1999 - 05.2002 | View |
Rear Axle Shaft Bearing for Toyota Vans ️
This rear axle shaft bearing is a critical support part inside the rear axle housing. It is needed to keep the axle shaft perfectly centered while it spins, so the wheel turns smoothly with minimal friction. A healthy bearing protects the axle, seals, and hub area from extra heat and side-load stress, especially on heavy people-movers and cargo vans.
How It Works ⚙️
The bearing uses hardened steel rollers/races to carry vehicle weight and axle loads while allowing the shaft to rotate freely. It holds tight tolerances, keeping the shaft aligned, reducing vibration, and helping the rear differential deliver power cleanly to the wheels.
What Happens If It’s Worn or Broken
A failing bearing often starts with a humming or growling noise that rises with speed. As wear increases, the wheel can develop play, ABS tone rings may read erratically, seals can leak gear oil onto brakes, and overheating can damage the axle shaft. In severe cases, the bearing can seize or collapse, risking loss of control and costly axle repairs.
Compatible Models ✅
- Granvia/Grand Hiace
- Hiace/Hiace S.b.v
- Regius/Touring Hiace
