  • 9031150047 Toyota OIL SEAL, FRONT DRIVE SHAFT, LH

9031150047 Toyota OIL SEAL, FRONT DRIVE SHAFT, LH, Price: 9.62$, Weight: 0.048kg

    • Make Number Name Availability Weight, kg Ship in, Days Price

    Toyota

    9031150047

    OIL SEAL, FRONT DRIVE SHAFT, LH

    		 97

    0.048

    2-3

    9.62$


    Substitutions

    Make Number Name Availability Weight, kg Processing, days Price
    Musashi
    9031150035
    OIL SEAL T-1366
    		339
    0.058
    4-5
    3.98$

    FEBEST
    95HBY49801118L
    DRIVE SHAFT OIL SEAL 47.6X80.1X10.9X17.5
    		36
    0.058
    2-3
    1.74$

    Toyota
    9031150035
    OIL SEAL, FRONT DRIVE SHAFT, LH
    		0
    0.058
    -
    9.66$
    		 Not Available
    Toyota
    9031150024
    OIL SEAL, FRONT DRIVE SHAFT, LH
    		0
    0.055
    -
    9.63$
    		 Not Available

    Compatibility

    DescriptionModelOptionsProd PeriodDiagram
    ACV40,GSV40ACV40L-AEMNKWATM,MTM: MANUAL TRANSMISSION; Driver's Position: LEFT-HAND DRIVE VEHICLES; Grade: LE TYPE; Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (2AZFE) 2400CC 16-VALVE DOHC EFI01.2006 - 08.2011 View
    DescriptionModelOptionsProd PeriodDiagram
    ACV40,AHV40,GSV40ACV40R-DEMDKQATM,MTM: MANUAL TRANSMISSION; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Grade: ALTISE TYPE; Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (2AZFE) 2400CC 16-VALVE DOHC EFI; Destination: AUSTRALIA06.2006 - 10.2011 View
    DescriptionModelOptionsProd PeriodDiagram
    AZE141,ZRE142AZE141L-DEMSKAATM,MTM: MANUAL TRANSMISSION; Grade: XRS TYPE; Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (2AZFE) 2400CC 16-VALVE DOHC EFI; Destination: UNITED STATES OF AMERICA01.2008 - 08.2013 View
    DescriptionModelOptionsProd PeriodDiagram
    CE140,NZE141,ZRE14#,ZZE14#CE140R-AEMDSATM,MTM: MANUAL TRANSMISSION; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Body: SEDAN; Grade: XLI TYPE; Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (2C) 2000CC DIESEL; Destination: GENERAL COUNTRIES08.2007 - 11.2013 View
    DescriptionModelOptionsProd PeriodDiagram
    CE140,NDE140,NZE140,ZRE14#,ZZE14#CE140R-GEMNSPATM,MTM: MANUAL TRANSMISSION; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Grade: 2.0D SALOON TYPE; Fuel Induction: DIESEL; Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (2C) 2000CC DIESEL; Destination: PAKISTAN08.2008 - 06.2014 View
    DescriptionModelOptionsProd PeriodDiagram
    AZE14#,ZRE142AZE141L-DHMNKKATM,MTM: MANUAL TRANSMISSION; Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (2AZFE) 2400CC 16-VALVE DOHC EFI; Destination: CANADA01.2008 - 12.2010 View
    DescriptionModelOptionsProd PeriodDiagram
    ACA3#,ALA3#,GSA33,ZSA3#ACA30R-AWMGKWATM,MTM: MANUAL TRANSMISSION; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Grade: A TYPE; Grade: G TYPE; Fuel Induction: HIGH EFFICIENCY TWIN CAM; Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (1AZFE) 2000CC 16-VALVE DOHC EFI; Destination: EUROPE11.2005 - 12.2012 View
    DescriptionModelOptionsProd PeriodDiagram
    AZE151AZE151L-FHMNKKATM,MTM: MANUAL TRANSMISSION; Body: HATCHBACK; Engine: (2AZFE) 2400CC 16-VALVE DOHC EFI; Destination: CANADA03.2010 - 12.2015 View

    LH Front Drive Shaft Oil Seal for Toyota Transaxle

    This precision seal sits where the left CV axle enters the gearbox. Its job is simple but critical: keep transmission/gear oil in, and keep dust and water out. A healthy seal protects differential bearings, clutch packs (in AT), and the inner CV joint. It is a must-replace item whenever the axle is removed, or when you see oil mist around the inner joint.

    Why you need it

    Leaks starve the transmission of lubrication, raise temperatures, and invite grit that chews the axle journal. Swapping in a fresh LH axle seal restores proper fluid retention, preserves shift quality, and stops driveway spots. It also prevents ABS sensor fouling from oily dirt.

    How it works

    A steel-cased body anchors in the housing. The primary elastomer lip, backed by a garter spring, rides the axle surface and holds a micro oil film for sealing at speed. A secondary dust lip blocks road debris. Quality compounds (NBR/FKM) resist heat, additives, and road splash for long life. ⚙️

    What happens if it’s broken

    • ATF or gear oil dripping from the left inner joint area
    • Burnt smell as oil hits the exhaust
    • Shudder or harsh shifts from low fluid
    • Differential whine and bearing wear
    • Contaminated CV boot, ABS signal errors

    Tech tips for a clean install

    Inspect and polish the axle journal; replace a grooved stub. Lightly oil the lip. Drive the seal square with a proper driver—never hammer the inner lip. Verify axle snap-ring engagement. After install, top off fluid, road test, and recheck for seepage. ✅

    Compatibility

    • Camry
    • Camry/Aurion/Hv
    • Corolla
    • Corolla Sed/Wg
    • Corolla/Altis
    • Matrix
    • Rav4
    • Scion Xb
