9031146004 SEAL, OIL(FOR CAMSHAFT SETTING)
Images
Compatibility
Toyota 9031146004
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| GXE1#,JCE1#,SXE10 | SXE10-AEAVF | ATM,MTM: AUTOMATIC TRANSMISSION; Body: SEDAN; Engine: (3SGE) 2000CC 16-VALVE DOHC EFI | 10.1998 - 07.2005 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| AT211,CT216,ST21# | ST215G-DWPVF | ATM,MTM: AUTOMATIC TRANSMISSION; Body: WAGON; Grade: GT TYPE; Gear Shift Type: ATM, 4-SPEED FLOOR SHIFT; Engine: (3SGE) 2000CC 16-VALVE DOHC EFI | 08.1997 - 09.2002 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| ST20# | ST202-BLMVF | ATM,MTM: MANUAL TRANSMISSION,5-SPEED FLOOR SHIFT; Body: LIFTBACK; Grade: SS-2 TYPE; Engine: (3SGE) 2000CC 16-VALVE DOHC EFI | 09.1993 - 08.1999 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| SW20 | SW20-ACPQF | ATM,MTM: AUTOMATIC TRANSMISSION; Body: COUPE (STANDARD ROOF); Grade: G,G LIMITED TYPE; Gear Shift Type: ATM, 4-SPEED FLOOR SHIFT; Engine: (3SGE) 2000CC 16-VALVE DOHC EFI | 12.1989 - 08.1999 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| SXA1# | SXA10W-AZMSF | ATM,MTM: MANUAL TRANSMISSION; NO. Of Doors: 3-DOOR; Body Shape: WIDE BODY; Grade: G TYPE; Engine: (3SGE) 2000CC 16-VALVE DOHC EFI | 08.1996 - 05.2000 | View |
Information
Camshaft Timing Oil Seal — Keep Your Engine Dry and Accurate ️
This precision lip seal sits where the camshaft exits the cylinder head. Its job is simple but vital: lock engine oil inside and keep dust and moisture out. With a healthy seal, your valve timing stays stable, VVT-i reacts fast, and the timing belt/chain stays clean.
Why this part is needed
It maintains oil pressure around the cam journals, prevents leaks that can soak belts or sensors, and protects the timing area from grime. A tight seal supports smooth starts, steady idle, and long component life.
How it works
A heat-resistant rubber body with a spring-loaded lip hugs the spinning camshaft. A micro oil film lubricates the lip, while fine grooves return oil inward. Press-fitted into the head or cover, it withstands heat, vibration, and crankcase pulses.
If the seal is worn or damaged
Expect oil stains, burning oil smell, noisy cold starts, rough idle, and rising oil use. Leaked oil can swell a timing belt or spray a chain, risking slip or stretch. Low oil may trigger warnings and harm the catalytic converter over time.
Compatibility
- Altezza/Altezza Gita
- Caldina
- Celica
- MR2
- RAV4
