8421060030 SWITCH ASSY, BACK-UP LAMP
Images
2 Images
Compatibility
Toyota 8421060030
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| GXE1#,JCE1#,SXE10 | SXE10-AEFVF | ATM,MTM: MANUAL TRANSMISSION; Body: SEDAN; Engine: (3SGE) 2000CC 16-VALVE DOHC EFI | 10.1998 - 07.2005 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| BU1##,2##,RZU100,140,XZU130,140 | XZU140-TKMQS3 | ATM,MTM: MANUAL TRANSMISSION; Seating Capacity: 3-SEATER; Building Condition: INCOMPLETE VEHICLES (CAB & CHASSIS); Deck,cab: HIGH DECK (WOODEN); Rear Tire: DOUBLE TIRE; Body: TRUCK; Fuel Induction: DIESEL; Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (J05C) 5300CC DIESEL; Loading Capacity: 3 TONS | 08.1997 - 05.1999 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| BU10#,11#,14#,21#,22#,YU210,RZU100 | YU210R-TKMQSN3 | Building Condition: INCOMPLETE VEHICLES (CAB & CHASSIS); Deck,cab: SINGLE CAB,FLAT; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Rear Tire: DOUBLE TIRE; Fuel Induction: CARBURETOR SYSTEM(GASOLINE); Engine: (4Y) 2200CC; Loading Capacity: 3 TONS; Destination: SOUTH AFRICA | 05.1995 - 12.2002 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| GRJ200,URJ202,UZJ200 | GRJ200L-GNMNKC | ATM,MTM: MANUAL TRANSMISSION; Grade: GX TYPE; Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (1GRFE) 4000CC 24-VALVE DOHC EFI | 12.2007 - 01.2009 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| UZJ100 | UZJ100L-GNAEKA | ATM,MTM: AUTOMATIC TRANSMISSION; Gear Shift Type: ATM, 5-SPEED FLOOR SHIFT; Engine: (2UZFE) 4700CC 32-VALVE DOHC EFI | 08.2002 - 08.2007 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| FJ80,FZJ80,HDJ81,HZJ81 | HZJ81V-RNMNS | ATM,MTM: MANUAL TRANSMISSION,5-SPEED FLOOR SHIFT; Grade: GX,GX LIMITED TYPE; Fuel Induction: DIESEL; Engine: (1HZ) 4200CC DIESEL | 01.1990 - 05.1993 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| AE10# | AE101-BCMXR | ATM,MTM: MANUAL TRANSMISSION; Body: COUPE; Grade: GT-Z TYPE; Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (4AGZE) 1600CC DOHC EFI SUPER CHARGER | 06.1991 - 05.1995 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| NCP1#,SCP11 | SCP11-BEMNK | ATM,MTM: MANUAL TRANSMISSION; Grade: F TYPE; Engine: (1SZFE) 1000CC 16-VALVE DOHC EFI | 08.1999 - 11.2005 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| JZA80 | JZA80L-ALFVZA | ATM,MTM: MANUAL TRANSMISSION; Body: LIFTBACK; Fuel Induction: TWIN CAM,TURBO; Gear Shift Type: MTM, 6-SPEED FLOOR SHIFT; Engine: (2JZGTE) 3000CC 24-VALVE DOHC EFI TURBO; Destination: UNITED STATES OF AMERICA | 05.1993 - 08.1998 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| NCP1#,SCP1# | SCP10-AHMNK | ATM,MTM: MANUAL TRANSMISSION; NO. Of Doors: 5-DOOR; Grade: F TYPE; Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (1SZFE) 1000CC 16-VALVE DOHC EFI | 01.1999 - 01.2005 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| NCP1#,NLP10,SCP10 | SCP10R-AHMRKW | ATM,MTM: MANUAL TRANSMISSION; NO. Of Doors: 5-DOOR; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Grade: TERRA TYPE( -0212),STANDARD TYPE(0212- ); Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (1SZFE) 1000CC 16-VALVE DOHC EFI | 01.1999 - 12.2002 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| NCP1#,SCP10 | SCP10R-AHMRK | ATM,MTM: MANUAL TRANSMISSION; NO. Of Doors: 5-DOOR; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Engine: (1SZFE) 1000CC 16-VALVE DOHC EFI; Destination: GENERAL COUNTRIES | 03.1999 - 08.2005 | View |
Information
Back-Up Lamp Switch: Essential for Safe Reversing
Ensuring safety while maneuvering a vehicle in reverse is critical. The back-up lamp switch, an integral component of your vehicle's safety system, serves this purpose. It activates the reverse lights, alerting pedestrians and other motorists that your car is backing up. These switches are engineered to work seamlessly with your vehicle's electrical system, providing a signal when the gear lever is shifted into reverse.
The Mechanics of the Switch
The back-up lamp switch typically operates on a simple mechanism: it's either a mechanical switch that gets engaged with the shift linkage or an electronic sensor connected to the vehicle's transmission. When you shift into reverse, the switch closes the circuit, allowing current to flow to the reverse lamps, illuminating them instantly.
Consequences of a Faulty Switch
If the back-up lamp switch fails, you may find yourself without an essential safety feature. Not only does this decrease the visibility of your vehicle while reversing, particularly in low-light conditions, but it can also fail safety inspections in many regions, as functioning reverse lights are a legal requirement.
Compatible Car Models:- Altezza/Altezza Gita
- Dyna 200/Toyoace G25
- Dyna200
- Land Cruiser
- Land Cruiser 100
- Land Cruiser Van
- Lvn/Cre/Trn/Mrn
- Platz
- Supra
- Vitz
- Yaris
- Yaris/Echo (3D,5D)
