6941526020 STOPPER, SLIDE DOOR DOWN FEMALE
Images
Compatibility
Toyota 6941526020
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| MNH10 | MNH10R-PFPSK | Seating Capacity: 7-SEATER; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Grade: MS TYPE; Gear Shift Type: ATM, 4-SPEED FLOOR SHIFT; Engine: (1MZFE) 3000CC 24-VALVE DOHC EFI; Destination: GENERAL COUNTRIES | 12.2003 - 04.2005 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| ANH1#,MNH1# | MNH15W-PRPSK | Seating Capacity: 8-SEATER; Grade: MS TYPE; Gear Shift Type: ATM, 4-SPEED FLOOR SHIFT; Engine: (1MZFE) 3000CC 24-VALVE DOHC EFI | 05.2002 - 04.2005 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| ATH10 | ATH10W-PRXGB | Seating Capacity: 8-SEATER; Engine: (2AZFXE) 2400CC 16-VALVE DOHC EFI | 07.2003 - 04.2008 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| GDH303 | GDH303W-RDTJY | Drive Train: 2 WHEEL DRIVE; Seating Capacity: 6-SEATER; NO. Of Doors: 5-DOOR; Building Condition: COMPLETELY BUILT UNIT; Roof: STANDARD ROOF; Body: STANDARD VAN; Grade: PREMIUM TYPE; Gear Shift Type: ATM, 6-SPEED FLOOR SHIFT; Engine: (1GDFTV) 2800CC DIESEL TURBO | 12.2019 - ... | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| GDH30#,32#,GRH30#,32# | GRH322R-EDTDH | ATM,MTM: AUTOMATIC TRANSMISSION; NO. Of Doors: 4-DOOR; Roof: HIGH-ROOF; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Gear Shift Type: ATM, 6-SPEED FLOOR SHIFT; Engine: (7GRFKS) 3500CC 24-VALVE DOHC; Destination: GENERAL COUNTRIES | 03.2019 - ... | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| GDH2##,KDH2##,LH2##,TRH2## | TRH223R-LETDKQ | Seating Capacity: 14-SEATER; NO. Of Doors: 4-DOOR; Roof: HIGH-ROOF; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Body: COMMUTER; Grade: STANDARD TYPE; Fuel Induction: HIGH EFFICIENCY TWIN CAM; Gear Shift Type: ATM, 6-SPEED FLOOR SHIFT; Engine: (2TRFE) 2700CC 16-VALVE DOHC EFI; Destination: AUSTRALIA | 01.2015 - 02.2019 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| KDH2##,TRH2## | TRH229W-LDPNK5 | Drive Train: 4 WHEEL DRIVE; Seating Capacity: 10-SEATER; NO. Of Doors: 4-DOOR; Building Condition: TECS SPECIAL PURPOSE VEHICLE; Roof: HIGH-ROOF; Body: WAGON; Grade: GRAND CABIN; Gear Shift Type: ATM, 4-SPEED FLOOR SHIFT; Engine: (2TRFE) 2700CC 16-VALVE DOHC EFI | 01.2005 - 05.2012 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| AZR6# | AZR65G-BRESH | Seating Capacity: 8-SEATER; Grade: Z TYPE; Gear Shift Type: CONTINUOUSLY VARIABLE TRANSMISSION; Engine: (1AZFSE) 2000CC 16-VALVE DOHC EFI | 08.2004 - 06.2007 | View |
Information
Lower Sliding Door Receiver Stopper for Toyota Vans
This small but critical piece sits in the lower track and acts as the receiver/stop for the sliding door. It cushions the final travel, locks alignment, and keeps the door flush with the body. Perfect OE-style replacement (OE ref: 69415-26020) for quiet, precise operation and long roller life.
Why this part is needed ✅
It stabilizes the door at close, damps impact, reduces rattle, and prevents metal-to-metal contact. With a healthy stopper, the latch engages smoothly, seals work better, and the door glides without harsh knocks.
How it works
Mounted on the lower rail area, the “female” block receives the matching pin/guide on the door. As the door reaches the end of travel, it centers and cushions the assembly, distributing load away from rollers and hinges, improving alignment and safety.
What happens if it’s worn or broken ⚠️
Expect clunks over bumps, door not sitting flush, hard closing, wind noise, water leaks, and faster wear of lower/center rollers. In severe cases the latch may not hold consistently, the warning light may stay on, and track damage can follow.
Tech tips
Inspect rollers and striker together, clean the track, apply light silicone grease, and tighten mounting bolts evenly. Adjust door height and in/out after install for a silent, solid close.
Compatibility
- Alphard
- Alphard G/V
- Alphard Hv
- Granace
- Grnva/Hiace/Mjsty
- Hiace
- Hiace/Regiusace
- Noah/Voxy
