5220960060 CUSHION SUB-ASSY, REAR END BODY MOUNTING, UPPER
Images
3 Images
Compatibility
Toyota 5220960060
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| KZJ9#,LJ9#,RZJ9#,VZJ9# | VZJ95R-GKPNKQ | ATM,MTM: AUTOMATIC TRANSMISSION; NO. Of Doors: 5-DOOR; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Grade: GX TYPE; Fuel Induction: ELECTRIC FUEL INJECTION SYSTEM; Engine: (5VZFE) 3400CC EFI; Destination: AUSTRALIA | 04.1996 - 09.2002 | View |
Information
Rear Upper Body Mount Cushion – Frame-to-Body Isolator
This rear body-to-frame cushion supports the tail end of the vehicle body and isolates it from the chassis. It cuts noise and vibration, keeps panels aligned, and protects the shell when driving on rough roads or carrying loads. If your ride feels harsher, the tailgate sits uneven, or you hear clunks over bumps, it’s time to renew this mount.
Why this part is needed ✅
It maintains correct body height, stops metal-to-metal contact, and reduces stress on welds and glass. Fresh mounts restore cabin comfort and extend the life of surrounding parts.
How it works ⚙️
A molded rubber cushion with a steel sleeve centers the body bolt. When torqued, the rubber compresses and absorbs shocks, filtering NVH while holding the body firmly in position.
What happens if it’s worn or broken ❗
Expect rattles, rear-end squeaks, crooked panel gaps, steering shimmy from misalignment, faster bushing wear nearby, and possible exhaust or bumper contact. Long-term, it can crack body seams and loosen hardware.
Installation tips
Replace in pairs, torque with vehicle on its wheels, inspect bolts and sleeves, and re-check torque after settling. Use corrosion protection on hardware.
Compatibility
- Land Cruiser 90
