4874042020 Toyota ARM ASSY, REAR SUSPENSION, NO.2 LH, Price: 124.59$, Weight: 3.565kg
| Make | Number | Name | Availability | Weight, kg | Ship in, Days | Price |
|---|---|---|---|---|---|---|
Toyota |
4874042020 |
ARM ASSY, REAR SUSPENSION, NO.2 LH |
33 |
3.565 |
2-3 |
124.59$ |
Originals
| Make | Number | Name | Availability | Weight, kg | Processing, days | Price | |
|---|---|---|---|---|---|---|---|
| Toyota |
ARM ASSY, REAR SUSPENSION, NO.2 LH
|
3 |
4.1
|
|
149.51$
|
Substitutions
| Make | Number | Name | Availability | Weight, kg | Processing, days | Price | |
|---|---|---|---|---|---|---|---|
| FEBEST |
ARM BUSH FOR REAR ARM
|
20 |
0.217
|
2-3
|
8.07$
|
Compatibility
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| ASU60 | ASU60R-ANTMT | ATM,MTM: AUTOMATIC TRANSMISSION; Seating Capacity: 5-SEATER; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Body: WAGON; Fuel Induction: TURBO SYSTEM; Gear Shift Type: ATM, 6-SPEED FLOOR SHIFT; Engine: (8ARFTS) 2000CC 16-VALVE DOHC EFI TURBO; Destination: GENERAL COUNTRIES | 05.2017 - 05.2020 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| ASU6#,AVU65,ZSU6# | ZSU60W-ANXSP | ATM,MTM: CONTINUOUSLY VARIABLE TRANSMISSION; Seating Capacity: 5-SEATER; Body: WAGON; Grade: PROGRESS TYPE; Fuel Induction: HIGH EFFICIENCY TWIN CAM (VALVEMATIC); Engine: (3ZRFAE) 2000CC 16-VALVE DOHC EFI | 05.2017 - 05.2020 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| ACA3#,ALA3#,GSA33,ZSA3# | GSA33R-ANAXKQ | ATM,MTM: AUTOMATIC TRANSMISSION; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Grade: A TYPE; Grade: X TYPE; Fuel Induction: HIGH EFFICIENCY TWIN CAM; Gear Shift Type: ATM, 5-SPEED FLOOR SHIFT; Engine: (2GRFE) 3500CC 24-VALVE DOHC EFI; Destination: AUSTRALIA | 08.2007 - 12.2012 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| QEA38 | QEA38L-CNDGSA | Seating Capacity: 5-SEATER; Driver's Position: LEFT-HAND DRIVE VEHICLES; Body: WAGON; Engine: (EM) ELECTRIC MOTOR | 04.2012 - 08.2014 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| ACA3#,GSA33 | GSA33W-BPAGK | ATM,MTM: AUTOMATIC TRANSMISSION; Seating Capacity: 7-SEATER; Grade: 350S TYPE; Gear Shift Type: ATM, 5-SPEED FLOOR SHIFT; Engine: (2GRFE) 3500CC 24-VALVE DOHC EFI | 08.2007 - 12.2012 | View |
Left Rear Suspension Arm (No.2) for Toyota SUVs
This OE-spec rear link keeps your wheel pointed straight and your tires flat on the road. It ties the rear knuckle to the subframe and locks in factory toe geometry. Strong steel and tuned rubber bushings manage cornering loads, braking forces, and road shocks, giving quiet, precise handling and long tire life.
Why you need it ✅
With age, bushings crack or soften. Impacts can bend the arm. When geometry drifts, the vehicle wanders, stability control works harder, and tires scrub away fast. Replacing the arm restores alignment points the cam bolt cannot fix alone.
How it works
The fixed-length arm uses bonded bushings to filter vibration while holding a set toe angle. It works together with the other rear links to keep the wheel path true through bumps and turns, maintaining traction and braking balance.
If the arm is damaged ⚠️
- Clunking over bumps
- Rear-end sway or pull
- Feathered/inside tire wear
- ABS/VSC lights after hits
- Longer stopping distance
Install tips
Torque bushings at ride height. Replace bolts if stretched. Finish with a 4-wheel alignment.
Compatibility
- Harrier
- Harrier/Hybrid
- Rav4
- Rav4 Ev
- Rav4/Vanguard
