4870260090 Toyota BUSH SUB-ASSY, Price: 29.75$, Weight: 0.302kg

    • Make Number Name Availability Weight, kg Ship in, Days Price

    Toyota

    4870260090

    BUSH SUB-ASSY

    		 3981

    0.302

    2-3

    29.75$


    Originals

    Make Number Name Availability Weight, kg Processing, days Price
    Toyota
    4870260090
    BUSH SUB-ASSY
    		606
    0.347
     Dispatch 24h
    35.70$

    ASIMCO
    4870260090
    SUSPENSION BUSH-48702-60090-ASIMCO THAILAND
    		144
    0.345
    4-5
    3.67$

    TERADA
    4870260090
    CONTROL ARM BUSH
    		0
    0.345
    4-5
    6.61$
    		 Not Available

    Substitutions

    Make Number Name Availability Weight, kg Processing, days Price
    RBI
    T25HD100E
    BUSH LOWER ARM L CRUISER
    		110
    0.345
    4-5
    6.72$

    CTR
    CVT39
    BUSH UPPER ARM RR
    		558
    0.764
    4-5
    4.93$

    Good Rubber Co LTD
    GT31048
    BUSH. SUSPENSION
    		50
    0.345
    2-3
    4.18$

    Good Rubber Co LTD
    4870260090GR
    ARM BUSHING
    		150
    0.345
    2-3
    3.70$

    FEBEST
    TAB132
    ARM BUSH FOR LATERAL CONTROL ARM
    		0
    0.351
    -
    6.52$
    		 Not Available
    SCHNIEDER
    TYS3501336
    ARM BUSHING LAND CRUISER LEXUS LX470 [98-07] RR UPPER
    		0
    0.345
    7-10
    3.07$
    		 Not Available

    Suspension Bushing Assembly for Toyota — Purpose

    This precision rubber‑metal bushing sits in the rear suspension arm and anchors the arm to the chassis. Its job is to keep wheel alignment true, absorb road shocks, and allow smooth pivoting of the arm under load. If you want factory feel, quiet ride, and predictable handling, this is the small part that makes a huge difference.

    How It Works ⚙️

    The unit combines an inner steel sleeve, a vulcanized elastomer core, and an outer steel shell. Pressed into the arm, it lets the arm rotate slightly around the inner sleeve while the bonded rubber controls movement. This isolates vibration, maintains toe and camber, and keeps braking and cornering stable.

    What Happens When Worn or Broken ❗

    Symptoms include clunks over bumps, rear‑end wander, steering correction on straight roads, uneven tire wear, and longer braking distances. Excess play can trigger metal‑to‑metal contact, damaging the arm and subframe. Left unchecked, it stresses shocks and tires, and can affect ABS/ESP behavior.

    Build & Fitment ✅

    OEM‑grade rubber hardness, corrosion‑treated sleeves, and exact press fit ensure quiet operation and long life on Toyota SUVs and sedans. Designed for direct replacement.

    Tech Tips for Replacement

    • Press in/out with proper support; align orientation marks.
    • Tighten pivot bolts at normal ride height.
    • Replace in pairs and perform wheel alignment after install.
