3123060181 Toyota BEARING ASSY, CLUTCH RELEASE, Price: 61.91$, Weight: 0.502kg
| Make | Number | Name | Availability | Weight, kg | Ship in, Days | Price |
|---|---|---|---|---|---|---|
Toyota |
3123060181 |
BEARING ASSY, CLUTCH RELEASE |
343 |
0.502 |
2-3 |
61.91$ |
Originals
| Make | Number | Name | Availability | Weight, kg | Processing, days | Price | |
|---|---|---|---|---|---|---|---|
| Toyota |
BEARING ASSY, CLUTCH RELEASE
|
84 |
0.577
|
|
74.29$
|
Compatibility
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| FJ80,HDJ80,HZJ80,FZJ80 | FZJ80L-GCMRU | ATM,MTM: MANUAL TRANSMISSION; Driver's Position: LEFT-HAND DRIVE VEHICLES; Grade: STANDARD TYPE; Fuel Induction: CABURETOR SYSTEM(GASOLINE); Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (1FZF) 4500CC; Destination: GENERAL COUNTRIES | 01.1992 - 09.2001 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| FZJ10#,HDJ100,HZJ105,UZJ100 | FZJ105R-GNMNKQ | ATM,MTM: MANUAL TRANSMISSION; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Grade: GX TYPE; Fuel Induction: ELECTRIC FUEL INJECTION SYSTEM; Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (1FZFE) 4500CC EFI; Destination: AUSTRALIA | 01.1998 - 08.2002 | View |
Premium Clutch Release Bearing for Toyota 4x4
This clutch release (throw-out) bearing keeps your Toyota’s manual transmission shifting smooth under load, towing, and off-road. Built for quiet operation and long service life, it delivers precise clutch disengagement and protects the rest of the clutch system.
Why this part is needed ✅
- Transfers pedal force to the pressure plate diaphragm spring
- Prevents clutch drag, gear grind, and hard shifting
- Ensures clean launch and smooth gear changes
How it works ⚙️
When you press the clutch, the fork pushes the bearing along the transmission input shaft collar. The sealed bearing face contacts the pressure plate fingers, releasing clamp force so the disc freewheels. High-temp grease and hardened races keep it running cool and quiet.
What happens if it’s bad ❗
- Squeal or chirp when pressing the pedal
- Notchy shifts, clutch drag, or vehicle creep
- Vibration through the pedal; premature pressure plate wear
- In severe cases, seizure that damages fork or front cover
Build highlights
- Precision-ground races, low runout
- Sealed, high-temperature lubricant
- Direct-fit geometry for Toyota manual gearboxes
Tech tip
Replace with the clutch kit; inspect fork pivot and sleeve, lightly grease contact points, and verify free play.
- Land Cruiser
- Land Cruiser 100
