30620T800A CYLINDER ASSY-CLUTCH OPERATING
Images
Compatibility
Nissan 30620T800A
| Body Style | Engine | Frame | Vehicle Grade | Market | Model | Model Year From | Diagram |
|---|---|---|---|---|---|---|---|
| LONG BODY | KA20DE | VPE25 | DX | Japan | E25 | 04.2001 | View |
| Body Style | Engine | Vehicle Grade | Market | Model | Model Year From | Options | Diagram |
|---|---|---|---|---|---|---|---|
| SINGLE CAB | KA24 | GL | General/Asia (RHD) | LCD22S | 02.2008 | WHEEL BASE:2WD LONG WHEEL BASE | View |
| Body Style | Engine | Vehicle Grade | Market | Model | Model Year From | Model Year To | Diagram |
|---|---|---|---|---|---|---|---|
| WINDOW VAN | KA24DE | DV | General/Asia (LHD) | E25 | 02.2006 | 08.2007 | View |
Information
Hydraulic Clutch Release Cylinder for Nissan ?
Why this part is needed
This hydraulic unit converts pedal force into precise push on the release fork, separating the pressure plate from the disc. It delivers smooth, quiet shifts, protects gearbox synchros, and keeps pedal effort light in traffic. A healthy cylinder means consistent bite point and confident launches ⚙️.
How it works
Fluid from the master flows through the line to this cylinder. The piston moves outward, driving the fork and release bearing to disengage the clutch. A precision-machined bore, corrosion-resistant body, and heat-rated seals hold pressure. The return spring resets the piston, while the bleed screw purges air for a firm pedal ?️.
What happens if broken
Worn seals or a scored bore cause a spongy pedal, low or sinking bite point, gear crunch, clutch drag at lights, or total loss of disengagement. You may see wetness at the dust boot and fluid drop in the reservoir. Keep driving and you risk damaged synchros and getting stranded. Replace promptly and bleed with fresh DOT 3/4 fluid ✅⚠️.
Compatibility
- Urvan
- Caravan
- Np300
