13566B1020 Toyota GUIDE, TIMING CHAIN, Price: 28.17$, Weight: 0.205kg
| Make | Number | Name | Availability | Weight, kg | Ship in, Days | Price |
|---|---|---|---|---|---|---|
Toyota |
13566B1020 |
GUIDE, TIMING CHAIN |
1 |
0.205 |
2-3 |
28.17$ |
Originals
| Make | Number | Name | Availability | Weight, kg | Processing, days | Price | |
|---|---|---|---|---|---|---|---|
| HABASHI |
13566B1020
|
TIMING GUIDE
|
5 |
0.236
|
4-5
|
8.29$
|
Compatibility
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| QNC2# | QNC21-BHSGK | ATM,MTM: AUTOMATIC TRANSMISSION; Grade: Z TYPE; Gear Shift Type: ATM, 4-SPEED COLUMN SHIFT; Engine: (3SZVE) 1500CC 16-VALVE DOHC EFI | 01.2006 - 07.2016 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| M502E,M512E | M512E-HQZE | Grade: S TYPE; Engine: (3SZVE) 1500CC 16-VALVE DOHC EFI | 12.2008 - 03.2012 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| J200E,J210E | J210E-GQPF | ATM,MTM: AUTOMATIC TRANSMISSION; Drive Train: 4 WHEEL DRIVE; Body: WAGON; Grade: G TYPE; Gear Shift Type: ELECTRONIC CONTROL 4SPEED AUTOMATIC TRANSMISSION; Engine: (3SZVE) 1500CC 16-VALVE DOHC EFI | 01.2006 - 05.2016 | View |
| Description | Model | Options | Prod Period | Diagram |
|---|---|---|---|---|
| AXP4#,NCP4#,SCP4# | SCP42L-EEPSKC | ATM,MTM: AUTOMATIC TRANSMISSION; NO. Of Doors: 4 DOOR; Driver's Position: LEFT-HAND DRIVE VEHICLES; Grade: GLS TYPE; Engine: (3SZFE) 1500CC 16-VALVE DOHC EFI; Destination: CHINA | 08.2006 - 02.2008 | View |
Timing Chain Guide – Essential for Engine Health
Why Is This Guide Needed
The timing chain guide keeps your engine’s timing chain correctly aligned and tensioned. This ensures the chain runs smoothly between gears, synchronizing the crankshaft and camshaft to maintain precise valve timing. Without this guide, the timing chain may shift or become slack.
How Does It Work
This component supports and stabilizes the timing chain as it moves at high speed inside the engine. It absorbs vibration and limits excess movement for continuous, accurate timing. The guide is typically made from durable plastic or metal, mounted securely inside the timing system.
Consequences of a Broken Guide
A worn or broken timing chain guide can cause excessive noise, poor engine performance, or even catastrophic engine damage if the timing chain slips. Immediate replacement avoids costly repairs and keeps your engine running reliably.
Compatible Car Models
- Bb
- Passo Sette
- Rush
- Vios/Soluna Vios
