  • 1320430030 Toyota BEARING SET, CONNECTING ROD

1320430030 Toyota BEARING SET, CONNECTING ROD, Price: 64.99$, Weight: 0.211kg

    • Make Number Name Availability Weight, kg Ship in, Days Price

    Toyota

    1320430030

    BEARING SET, CONNECTING ROD

    		 6

    0.211

    2-3

    64.99$


    Originals

    Make Number Name Availability Weight, kg Processing, days Price
    Toyota
    1320430030
    BEARING SET, CONNECTING ROD
    		2
    0.243
     Dispatch 24h
    77.99$


    Compatibility

    DescriptionModelOptionsProd PeriodDiagram
    KDY22#,23#,25#,26#,LY2##KDY261L-TBMGYW3Building Condition: INCOMPLETE VEHICLES (CAB & CHASSIS); Driver's Position: LEFT-HAND DRIVE VEHICLES; Rear Tire: DOUBLE TIRE; Engine: (1KDFTV) 3000CC DIESEL TURBO; Loading Capacity: 1.5 TONNE; Destination: EUROPE09.2006 - 02.2015 View
    DescriptionModelOptionsProd PeriodDiagram
    KDY2##,LY2##,RZY2##,TRY2##KDY290V-REMGYATM,MTM: MANUAL TRANSMISSION; Deck,cab: VAN; Building Condition: COMPLETELY BUILT UNIT; Rear Tire: DOUBLE TIRE; Fuel Induction: DIESEL COMMON RAIL INJECTION SYSTEM; Engine: (2KDFTV) 2500CC DIESEL TURBO; Loading Capacity: 1.5 TONNE08.2004 - 08.2007 View
    DescriptionModelOptionsProd PeriodDiagram
    KDH2##,LH2##,TRH2##KDH222R-LEMNYNSeating Capacity: 14-SEATER; NO. Of Doors: 4-DOOR; Roof: HIGH-ROOF; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Body: COMMUTER; Grade: GL TYPE; Fuel Induction: DIESEL COMMON RAIL INJECTION SYSTEM; Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (2KDFTV) 2500CC DIESEL TURBO; Destination: SOUTH AFRICA10.2006 - 12.2013 View
    DescriptionModelOptionsProd PeriodDiagram
    KLH1#,2#,LXH1#,2#,RCH1#,2#KLH22L-RRMRHWATM,MTM: MANUAL TRANSMISSION; Seating Capacity: 6-SEATER; Driver's Position: LEFT-HAND DRIVE VEHICLES; Body: 4 DOOR VAN; Grade: STANDARD TYPE; Fuel Induction: HIGH POWER DIESEL COMMON RAIL INJECTION SYSTEM; Engine: (2KDFTV) 2500CC DIESEL TURBO; Destination: EUROPE08.2001 - 11.2011 View
    DescriptionModelOptionsProd PeriodDiagram
    KDH2##,TRH2##KDH223B-LEPNYDrive Train: 2 WHEEL DRIVE; Seating Capacity: 15-SEATER; NO. Of Doors: 4-DOOR; Building Condition: COMPLETELY BUILT UNIT; Roof: HIGH-ROOF; Body: COMMUTER; Grade: GL,GRAND CABIN TYPE; Gear Shift Type: ATM, 4-SPEED FLOOR SHIFT; Engine: (1KDFTV) 3000CC DIESEL TURBO09.2007 - 12.2013 View
    DescriptionModelOptionsProd PeriodDiagram
    GDJ15#,GRJ150,KDJ150,TRJ150KDJ150R-GKAEYWATM,MTM: AUTOMATIC TRANSMISSION; NO. Of Doors: 5-DOOR; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Gear Shift Type: ATM, 5-SPEED FLOOR SHIFT; Engine: (1KDFTV) 3000CC DIESEL TURBO; Destination: EUROPE08.2017 - 06.2019 View
    DescriptionModelOptionsProd PeriodDiagram
    GDJ150,GRJ150,KDJ150,LJ150,TRJ15#KDJ150L-GKAEYVATM,MTM: AUTOMATIC TRANSMISSION; NO. Of Doors: 5-DOOR; Driver's Position: LEFT-HAND DRIVE VEHICLES; Gear Shift Type: ATM, 5-SPEED FLOOR SHIFT; Engine: (1KDFTV) 3000CC DIESEL TURBO; Destination: GULF CORPORATION COUNCIL08.2017 - 07.2020 View

    Engine Connecting Rod Bearing Set – OE-grade Big-End Shells

    This bearing set supports the joint between the connecting rod and the crankshaft. It keeps a precise oil film so the crank can spin smoothly under load. Fresh shells restore correct clearance, stabilize oil pressure, and protect the bottom end in hardworking Toyota engines used for hauling and long trips.

    Why you need it ️

    Over time, shells wear from high load, dirty oil, or overheating. Wear increases clearance, drops oil pressure, and invites metal-to-metal contact. Replacing them prevents knock, restores quiet operation, and extends crank and rod life.

    How it works ⚙️

    Two half-shells seat in the rod and cap. With proper “crush” and clearance, pressurized oil forms a hydrodynamic wedge between bearing and crank journal. The tri-metal surface handles shock loads while the soft overlay captures tiny debris, protecting the journal.

    If they fail

    Expect cold/hot knock, low oil pressure, glitter in oil, and rising temps. Continued driving risks spun bearing, seized rod, scored crank, or even a windowed block. Repair costs soar compared to timely replacement.

    Tech tips ✅

    Measure journals, select correct size (STD/undersize), check with Plastigage, use assembly lube, and torque rod bolts to spec. Keep caps matched and surfaces spotless.

    Compatibility

    • Dyna
    • Dyna/Toyoace
    • Hiace
    • Hiace/Hiace S.b.v
    • Hiace/Regiusace
    • Land Cruiser
    • Land Cruiser Prado
