  • 1301140052 Toyota RING SET, PISTON

1301140052 Toyota RING SET, PISTON, Price: 156.21$, Weight: 0.081kg

    • Make Number Name Availability Weight, kg Ship in, Days Price

    Toyota

    1301140052

    RING SET, PISTON

    		 2

    0.081

    2-3

    156.21$


    Substitutions

    Make Number Name Availability Weight, kg Processing, days Price
    Toyota
    1301140051
    RING SET, PISTON
    		0
    0.04
    -
    134.14$
    		 Not Available
    Toyota
    1301140030
    RING SET, PISTON
    		0
    0.043
    -
    57.38$
    		 Not Available
    Toyota
    1301140050
    RING SET, PISTON
    		0
    0.044
    -
    50.49$
    		 Not Available
    NPR
    SWT10223ZZSTD
    RING PISTON 1KRFE STD
    		0
    0.044
    4-5
    18.69$
    		 Not Available

    Compatibility

    DescriptionModelOptionsProd PeriodDiagram
    KGB10,WNB10KGB10R-AHMGKWATM,MTM: MANUAL TRANSMISSION; NO. Of Doors: 5-DOOR; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Grade: LEVEL 1 TYPE; Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (1KRFE) 1000CC 12-VALVE DOHC EFI02.2005 - 06.2014 View
    DescriptionModelOptionsProd PeriodDiagram
    KSP92,NCP96,SCP92KSP92-BEXNKATM,MTM: AUTOMATIC TRANSMISSION; Grade: X TYPE; Gear Shift Type: CONTINUOUSLY VARIABLE TRANSMISSION; Engine: (1KRFE) 1000CC 12-VALVE DOHC EFI11.2005 - 06.2012 View
    DescriptionModelOptionsProd PeriodDiagram
    KGJ10,NGJ10KGJ10-BGXRGATM,MTM: AUTOMATIC TRANSMISSION; Grade: 100X TYPE; Gear Shift Type: CONTINUOUSLY VARIABLE TRANSMISSION; Engine: (1KRFE) 1000CC 12-VALVE DOHC EFI11.2008 - 03.2016 View
    DescriptionModelOptionsProd PeriodDiagram
    KGC3#,NGC30KGC35-AHECKGrade: X TYPE; Engine: (1KRFE) 1000CC 12-VALVE DOHC EFI02.2010 - 04.2016 View
    DescriptionModelOptionsProd PeriodDiagram
    KSP130,NCP131,NHP130,NSP13#KSP130-AHXGKATM,MTM: CONTINUOUSLY VARIABLE TRANSMISSION; NO. Of Doors: 5-DOOR; Building Condition: COMPLETELY BUILT UNIT; Grade: JEWELA TYPE; Fuel Induction: HIGH EFFICIENCY TWIN CAM; Engine: (1KRFE) 1000CC 12-VALVE DOHC EFI12.2010 - 01.2020 View
    DescriptionModelOptionsProd PeriodDiagram
    KSP90,NLP90,NSP90,SCP90KSP90R-CGMRKWATM,MTM: MANUAL TRANSMISSION; NO. Of Doors: 3-DOOR; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Grade: TERRA TYPE( -0811),STANDARD TYPE(0811- ); Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (1KRFE) 1000CC 12-VALVE DOHC EFI01.2006 - 07.2011 View
    DescriptionModelOptionsProd PeriodDiagram
    KSP130,NHP130,NLP130,NSP130KSP130R-CHMGKWATM,MTM: MANUAL TRANSMISSION; NO. Of Doors: 5-DOOR; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Grade: LOUNGE TYPE; Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (1KRFE) 1000CC 12-VALVE DOHC EFI07.2011 - 07.2014 View

    Precision Piston Ring Kit for Toyota Compacts

    Restore tight engine compression, clean exhaust, and stable idle with this high-accuracy piston rings set. Built from heat-treated steel with low-friction coating, it keeps your city-friendly Toyota running smooth, efficient, and quiet.

    Why you need it

    Piston rings seal the combustion chamber, control oil on the cylinder wall, and carry heat from the piston to the block. Fresh rings stop blow‑by, reduce oil consumption, and bring back factory performance and fuel economy.

    How it works ⚙️

    The top compression ring holds combustion pressure. The second ring assists sealing and scrapes residual gases. The multi‑piece oil ring meters the oil film. Spring tension lets the rings expand to the bore, following cylinder shape through heat and load.

    When worn or broken

    Symptoms include hard starts, low power, rough idle, blue smoke, high oil use, fuel dilution, fouled plugs, and rising emissions. Long term, expect cylinder scoring and catalytic converter damage.

    Tech tips

    Light hone for crosshatch, measure end‑gap, check side clearance, clock gaps at 120°, oil during install, and verify bore taper/out‑of‑round.

    Compatibility

    • Aygo
    • Belta
    • Iq
    • Passo
    • Vitz
    • Yaris
    • Yaris/Hybrid
