  • 0449535250 Toyota SHOE KIT, REAR BRAKE

0449535250 Toyota SHOE KIT, REAR BRAKE, Price: 80.87$, Weight: 3.238kg

    • Make Number Name Availability Weight, kg Ship in, Days Price

    Toyota

    0449535250

    SHOE KIT, REAR BRAKE

    		 17

    3.238

    2-3

    80.87$


    Substitutions

    Make Number Name Availability Weight, kg Processing, days Price
    Toyota
    0449535220
    SHOE KIT, REAR BRAKE
    		0
    3.824
    -
    80.78$
    		 Not Available
    JFBK
    FN2803
    BRAKE SHOE
    		0
    3.724
    4-5
    34.33$
    		 Not Available

    Compatibility

    DescriptionModelOptionsProd PeriodDiagram
    GDH2##,KDH2##,LH2##,TRH2##TRH223R-LEMNKNSeating Capacity: 14-SEATER; NO. Of Doors: 4-DOOR; Roof: HIGH-ROOF; Driver's Position: RIGHT-HAND DRIVE VEHICLES; Body: COMMUTER; Grade: GL TYPE; Fuel Induction: HIGH EFFICIENCY TWIN CAM; Gear Shift Type: MTM, 5-SPEED FLOOR SHIFT; Engine: (2TRFE) 2700CC 16-VALVE DOHC EFI; Destination: SOUTH AFRICA12.2013 - ... View
    DescriptionModelOptionsProd PeriodDiagram
    GSK30,UCK3#,4#,VCK30,40UCK41L-PRBSKKATM,MTM: AUTOMATIC TRANSMISSION; Cab: DOUBLE CAB; Grade: SR5 TYPE; Deck: STANDARD DECK; Gear Shift Type: ATM, 5-SPEED COLUMN SHIFT; Engine: (2UZFE) 4700CC 32-VALVE DOHC EFI; Destination: CANADA08.2004 - 12.2006 View

    Rear Drum Brake Shoe Set — OE-Spec Replacement

    Why you need it

    This rear brake shoe kit restores safe stopping power when linings are worn, glazed, or oil-soaked. Fresh shoes give firm pedal feel, shorter braking distance, quieter operation, and strong parking brake hold. Replacing them on time also protects the drum from scoring and costly machining.

    How it works

    In a drum system, hydraulic pressure moves the wheel‑cylinder pistons, pushing the curved shoes outward. The friction lining grips the drum to slow the vehicle. Return springs pull the shoes back when you release the pedal, while a star adjuster keeps the gap correct. The parking brake lever spreads the shoes mechanically for solid hold on inclines.

    If worn or broken

    Expect longer stops, low pedal, weak handbrake, pulling to one side, scraping or squeal, vibration, hot smell, or rivets showing. Ignoring it can cause drum damage, brake fade on hills, uneven wear, and extended stopping distances. Always replace shoes as an axle set and inspect hardware.

    Install tips ⚙️

    Clean the backing plate, lightly lube contact pads, renew springs if weak, center the shoes, set the star adjuster, and bed-in with several medium stops. Keep grease off the linings. ✅

    Compatibility

    • Hiace
    • Tundra
